Width: 4.1 in
Height: 5.5 in
Length: 5.2 in
Memory: Non - Volatile
Accuracy: ± 0.2 %
Materials: FKM, Fluoroelastomer, Polycarbonate, Polyvinylidene, Fluoride
Beam Width: 2 in
Cable Type: Insulated Shielded
Insulation: Polyurethane
Resolution: 0.019 in
Configuration: USB PC Windows®USB 2.0 Memory: Non-volatile. The level sensor is configurable via our free PC software download and USB adaptor. The sensors are offered with and without USB connectors. Connectors can be used to configure any compatible level product. Download your free copy
Output Signal: Current
Signal invert: 4 to 20 mA or 20 to 4 mA
Data Interface: USB
Loop Resistance: 500 Ω @ 24 Vdc
Number of Wires: 2
Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA or hold last
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 4X
Media Compatibility: Alkaline solutions, Dilute Acids, Hydraulic Oil, Light Oil, Oil, Solvents, Water, Water-based fluids
Measuring Range, Max: 9.8 ft
Measuring Range, Min: 4 ft
Operating Pressure, Max: 30 psi
Process Connection Size: 1 in
Process Connection Type: NPT Male
Process Temperature, Max: 60 °C
Process Temperature, Min: -20 °C
Temperature Compensation: Automatic
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -35 °C
