Height: 25.4 mm
Accuracy: ± 0.5 %
Linearity: ± 0.5%
Materials: Stainless Steel
Force Type: Compression
Hysteresis: ± 0.5%
Cable Length: 5 ft
Overload, Max: 300% FS
Repeatability: ± 0.5%
Safe Overload: 150% FS
Load Cell Type: Button
Outer Diameter: 25.4 mm
Supply Voltage: 10 Vdc
Bridge Resistance: 350 Ω
Electrical Output: 2 mV/V
Enclosure Ratings: IP65
Supply Power Note: 10 Vdc, 15 Vdc maximum
Calibration Option: 5 POINT NIST
Load Cell Capacity: 5000 N
Zero/Balance Error: ± 2%
5-Point Calibration: 0%, 50%, 100%, 50%, 0%
Thermal Span Effect: 0.036% FSO/°C
Thermal Zero Effect: 0.009% FSO/°C
Electrical Connection: Cable
Full Scale Deflection: 0.003 in
Wiring/Connector Table: Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input
Process Temperature, Max: 71 °C
Process Temperature, Min: 16 °C
Operating Temperature, Max: 107 °C
Operating Temperature, Min: -54 °C
