Height: 0.4 in
Accuracy: ± 0.5 %
Linearity: ± 0.50%
Materials: Stainless Steel
Force Type: Compression, Tension
Hysteresis: ± 0.50%
Cable Length: 5 ft
Overload, Max: 300% FS
Repeatability: ± 0.20%
Safe Overload: 150% FS
Load Cell Type: In-line
Outer Diameter: 0.75 in
Supply Voltage: 5 Vdc
Bridge Resistance: 350 Ω
Electrical Output: 2 mV/V
Enclosure Ratings: IP54
Calibration Option: 5 POINT NIST
Load Cell Capacity: 10 lbF
Zero/Balance Error: ± 2%
5-Point Calibration: 0%, 50%, 100%, 50%, 0% (in tension)
Thermal Span Effect: ± 0.009% rdg/°C
Thermal Zero Effect: 0.009% FSO/°C
Electrical Connection: Cable
Full Scale Deflection: 0.003 in
Wiring/Connector Table: Green: (-) Output; White: (+) Output; Black: (-) Input; Red: (+) Input
Process Temperature, Max: 71 °C
Process Temperature, Min: 16 °C
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -53 °C
