Adhesive: SG496, SG401, TT300
Materials: Constantan, Polyimide
Pack Size: 10
Tolerance: ±1%
Elongation: 20000 µm/m to 25000 µm/m
Grid Style: Linear
Grid Width: 2 mm
Grid Length: 3 mm
Sensitivity: ±0.2%
Wire Length: 1 m
Gauge Factor: 2
Carrier Width: 3.9 mm
Input Voltage: 4 Vac
Carrier Length: 7.4 mm
Grid Thickness: 5 μm
Mechanical Life: >10^7 cycles
Carrier Thickness: 45 μm
Grid Length Range: 3 mm
Nominal Resistance: 120 Ω
Mechanical Life Note: >1 x 107 cycles at zero point variation ≤ 300 µm/m, 5 x 106 cycles at zero point variation ≤ 30 µm/m
Resistance Tolerance: ±0.35%
Electrical Connection: Wire Leads
Gauge Factor Tolerance: ± 1 %
Temperature Compensation: 10.8 x 10-6
Operating Temperature, Max: 155 °C
Operating Temperature, Min: -10 °C
Material Construction Option: Steel
