EMC: <0.15% of FS per EN61326-1 (industrial)
Width: 31.2 mm
Height: 34.8 mm
Length: 134.8 mm
Approvals: CE
Isolation: 100 MΩ @ 500 Vdc
Linearity: 0.0001
Input Type: Current, Signal
Protection: Short Circuit Protection: Yes +output to -output
Capacitance: 0.022 µF
Input Noise: 10 mV peak to peak @ 3 mV/V voltage mode (10 Vdc) 20 uA peak to peak current mode
Input Range: 90 mA, 0.5 mV/V to 4 mV/V in 0.5 steps
Sensitivity: Bridge : 1 to 8 mV/V @ 5 Vdc EXC, 0.5 to 4 mV/V for 10 Vdc EXC
Supply Power: 22 to 32 Vdc
Output Detail: Current: 4 to 20 mA, 12 mA zero ± 8 mA outputs field programmable, Voltage: ± 5 volts, ± 10 volts at 2 mA maximum
Output Signal: Current, Voltage
Response Time: 200 µs
Load Resistance: 700 Ω at 20 mA
Span Adjustment: ± 20 % fine ± 40 % coarse
Trim Pot Access: Behind connector endcaps
Calibration Note: Field Installed Shunt Calibration resistor with remote activation for bridge calibration
Input Range Note: Current: 90 mA maximum (must be capable of supplying 200 mA), Sensor Input: 0.5 mV/V to 4 mV/V in 0.5 steps
Bridge Resistance: 350 to 5000 Ω
Electrical Output: 4 to 20 mA, ± 5 V, ± 10 V @ 2 mA
Enclosure Ratings: IP65
Output Resistance: 60 Ω
Sensor Excitation: 5 or 10 Vdc field programmable; 30 mA @ 10 Vdc
Supply Power Note: 22 to 32 Vdc isolated from output
Supply Power Type: DC
Response Time Note: 200 µs (0 to 63%)
Long Term Stability: 0.1% of FS/year
Thermal Span Effect: 0.0025%/°F
Thermal Zero Effect: 0.001%/°F
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Zero Setting Adjustable Range: ± 30%
