RELATIVE HUMIDITY
Thin-Film Polymer Capacitor
Input Voltage Range: 6 to 30 Vdc, (polarity protected)
Range/Accuracy/Repeatability: 3 to 95% RH/±2% RH/±1% RH
Temperature Compensation: -20 to 85°C (4 to 185°F)
Current Output: 0~1 Vdc (0 to 100% RH)
Time Constant: (for 90% response at 25°C; in moving air, 1m/sec.)
Less than 20 seconds, 10 to 90% RH
Less than 30 seconds, 90 to 10% RH
TEMPERATURE
Thin-Film 100 Ω Platinum RTD (DIN 43760)
Input Voltage Range: 6 to 30 Vdc, (polarity protected)
Range: 0 to 100°C (32 to 212°F)
Accuracy: ±0.6°C (±1°F)
Repeatability: ±0.3°C (±0.5°F)
Current Output: 0~1 Vdc for 0 to 100°C
Time Constant: (for 60% response) Less than 2 sec in moving air (1m/sec) less than 10 sec in still air
MECHANICAL
Housing: Stainless steel NEMA 4 enclosure
Probe: 254 x 19 mm (10 x 0.75") dia., 305 mm (12") cable
Duct Flange: Removable, variable 25.4 to 227 mm (1 to 9") depth; 70 mm (2.75") dia., duct hole 21 mm (0.812") dia. 4 mtg holes. 4 mm (0.156") dia. (for #6 sheet metal screws) on 51 mm (2.00") dia. circle; wall mounting bracket included
Connections: 1 ⁄2" male NPT conductor with 1 m (3') braided/ shielded cable
Weight: 198 g (7 oz) with duct flange
Comes with mating connector, removable protective sensor filter, removable duct flange,
wall mounting bracket, and operator’s manual.
