OMEGA HHT-EU-LCD ເຄື່ອງສົ່ງສັນຍານຄວາມຊຸ່ມຊື່ນ/ອຸນຫະພູມຂອງພື້ນທີ່ອັນຕະລາຍ (0 ~ 100%, 16.5-28 VDC, LCD)
Relative Humidity Range: 0 to 100% RH.
Accuracy: ±2% 10 to 90% RH
Hysteresis: ±1%.
Repeatability: ±0.1% typical.
Temperature Limits: -40 to 140°F (-40 to 60°C).
Storage Temperature: -40 to 176°F (-40 to 80°C).
Compensated Temperature: -40 to 140°F (-40 to 60°C).
Power Requirements: 16.5-28 VDC
Output Signal: 4-20 mA, 2 channels for humidity/temperature models (loop power on RH).
Response Time: 15 s.
Electrical Connections: Screw terminal block.
Conduit Connection: 1/2 female NPT.
Drift: < 1% RH/year.
RH Sensor: Capacitance polymer.
Housing Material: Aluminum.
Display: Optional 2 line alpha numeric, 8 characters/line. Temperature display is °F/°C selectable.
Display Resolution: RH: 0.1%; Temperature: 0.1°F (0.1°C).
Enclosure Rating: NEMA 4X (IP66). FM Explosion- Proof, Class I Div. 1 Group B, C, D, Class II Div. 1 Group E, F, G, Class III Div. 1
Weight: 2 lb 8 oz (1134 g).
Compliance: CE, FM.
