OMEGA FV108 ເຄື່ອງວັດອັດຕາໄຫມ້ລົມ Vortex ແລະ ເຄື່ອງສົ່ງສະເພາະອຸນຫະພູມ (60 GPM, 1 1/2 in, ANSI Flange, IP 65 Type 1, IP 65 Type 12, IP 65 Type 27, IP 65 Type 3, IP 65 Type 4)
Weight: 55 lb
Accuracy: ± 2 %
Display Note: 3-digit, 7.62 mm (0.3") high numeric LED that flashes below setpoint
Display Type: LED
Installation: 10 pipe diameters upstream and 5 downstream recommended
Supply Power: 10 to 30 Vdc
Output Detail: Analog Output: 4 to 20 mA (600 Ω @ 24 Vdc) Alarm Output: SPST SSR, NO or NC operation, selectable; dual alarms for flow/temperature units FV101 and 102: 250 mA @ 30 Vdc up to 85°C (185°F) FV103 thru 108: 125 mA @ 30 Vdc up to 85°C (185°F) reduced current rating at higher temperatures
Pressure Type: Gauge
Repeatability: ±0.25%
Response Time: 0.9 to 7.5 sec
Alarm Deadband: 0.05
Control Output: SPST Relay, SSR Relay
Mounting Plates: N/A
Number of Digits: 3
Electrical Output: 4 to 20 mA, 125 mA SPST SSR
Enclosure Ratings: IP 65 Type 1, IP 65 Type 12, IP 65 Type 27, IP 65 Type 3, IP 65 Type 4
Materials, Wetted: FKM, PVDF
Supply Power Note: 10 to 30 Vdc @ 80 mA
Enclosure Material: N/A
Pressure Drop, Max: 1.3 psi
Response Time Note: User selectable from 0.9 to 7.5 seconds
Media Compatibility: Liquids
Electrical Connection: 5 - Pin Micro Male
Operating Pressure, Max: 200 psi
Process Connection Size: 1 1/2 in
Process Connection Type: ANSI Flange
Volumetric Flow Rate, Max: 4 GPM
Volumetric Flow Rate, Min: 60 GPM
Operating Temperature, Max: 99 °C
Operating Temperature, Min: 2 °C
