Length: 2.75 in
Weight: 1 lb
Accuracy: ± 0.5 %
K-Factor: 4100 pulses/gal
Output Detail: Minimum Output Amplitude: 30 mV Peak-to-Peak unscaled dc_pulse
Output Signal: DC Pulse
Overload, Max: 150% of maximum range
Repeatability: ±0.1%
Certifications: NIST Traceable Calibration
Electrical Output: Sinusoidal Wave
Materials, Wetted: 17-4 Stainless Steel, 304 Stainless Steel, Ceramic
Pressure Drop, Max: 3 psi
Media Compatibility: Liquids
Operating Pressure, Max: 5000 psi
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Volumetric Flow Rate, Max: 16 GPM
Volumetric Flow Rate, Min: 1.75 GPM
Required Straight Pipe, Min: 10 Pipe Diameters Upstream, 5 Downstream
