Height: 3.5 in
Weight: 1.5 lb
Accuracy: ± 5 %
Diameter: 2.5 in
Adjustments: Potentiometer
Switch Type: NPN, PNP
Cable Length: 6.5 ft
Output Signal: Current
Repeatability: ±1%
Response Time: 3 to 10 sec
Switch Rating: 400 mA
Probe Diameter: 0.625 in
Supply Voltage: 24 Vdc
Flow Indication: 8 LED Bar Graph
Insertion Length: 2 in
Enclosure Ratings: IP65, NEMA 4
Materials, Wetted: 316 Stainless Steel
Supply Power Note: 24 Vdc ±10%
Enclosure Material: Glass Filled Nylon
Switch Rating Note: FSW-9000: transistor NPN/PNP (400 mA) and 4 to 20 mA
Media Compatibility: Liquids
Electrical Connection: 1/2 NPT female Conduit with Cable
Linear Flow Rate, Max: 2 m/s
Linear Flow Rate, Min: 0.04 m/s
electrical-connection: 1/2 NPT female Conduit with Cable
Operating Pressure, Max: 4351 psi
Process Connection Size: 1 1/2 in
Process Connection Type: Tri-Grip Fitting
Process Temperature, Max: 80 °C
Process Temperature, Min: -20 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
