Height: 2.5 in
Weight: 1.5 lb
Accuracy: ± 10 %
Diameter: 3.5 in
Materials: Glass-Filled Nylon, 316 Stainless Steel
Adjustments: Potentiometer
Switch Type: SPDT NO/NC, Selectable
Cable Length: 6.5 ft
Repeatability: ±1%
Response Time: 1 to 10 sec
Switch Rating: 5 A
Flow Rate Note: Gas Velocity: 0.16 to 49 ft/s, Liquid Velocity: 0.09 to 9.84 ft/s
Pipe Size, Max: 4 in
Pipe Size, Min: 1 in
Supply Voltage: 24 Vdc
Flow Indication: Green LED: Flow rate above setpoint, Yellow LED: Flow is at above setpoint, Red LED: Flow is below setpoint
Insertion Length: 3 in
Enclosure Ratings: IP65, NEMA 4
Supply Power Note: 24 Vdc ±10%
Switch Rating Note: 5 A, 250 Vac
Media Compatibility: Gases, Liquids
Additional Features 1:
Electrical Connection: Cable Gland with Cable
Linear Flow Rate, Max: 49 ft/s
Linear Flow Rate, Min: 0.16 ft/s
Operating Pressure, Max: 4351 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 80 °C
Process Temperature, Min: -20 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
