Weight: 6 oz
Features: Number of Extra Disks Included: 1
Materials: Stainless Steel, Polyphenylene, FKM
Sensitivity: 10% @ upper end of range; 30% @ lower end of range
Switch Type: SPDT NO/NC, Selectable
Switch Rating: 15 A
Pipe Size, Max: 2.5 in
Pipe Size, Min: 1.5 in
Pressure Drop Note: 1 to 3" pipe, less than 1 psi; 4" and above, negligible
Pressure Drop, Max: 1 psi
Switch Rating Note: 15 A @ 125 or 250 Vac; 10,000,000 operations median
Media Compatibility: Liquids
Electrical Connection: Cable Gland for 1/4 in Cable with Screw Terminal block
Linear Flow Rate, Max: 10.8 ft/s
Linear Flow Rate, Min: 2.7 ft/s
Operating Pressure, Max: 100 psi
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Male
Volumetric Flow Rate, Max: 0 GPM
Volumetric Flow Rate, Min: 0 GPM
Electrical Connection Note: Electrical Cable Fitting: Water resistant for cable diameter 0.250" ±0.025"
Operating Temperature, Max: 93 °C
Operating Temperature, Min: 4 °C
Material Construction Option: Standard
