Accuracy: ± 1 %
Materials: Stainless Steel, Brass
Hysteresis: 10% at upper end of flow range, 30% at lower end of flow range (∆ Flow Rate to Activate/ Deactivate Switch)
Sensitivity: 10% @ upper end of range; 30% @ lower end of range
Switch Type: SPDT NO/NC, Selectable
Paddle Length: 1.3 in
Switch Rating: 15 A
Pipe Size, Max: 0 in
Pipe Size, Min: 0 in
Supply Voltage: 125 / 250 Vac
Enclosure Ratings: IP10, NEMA Type 1
Pressure Drop, Max: 1 psi
Switch Rating Note: 15 A, ½ hp at 125 or 250 Vac 0.5 A at 125 Vdc (tungsten lamp) 0.25 A @ 250 Vdc (tungsten lamp)
Media Compatibility: Liquids
Electrical Connection: 1/2 in NPS female Conduit with Screw Terminal block
Linear Flow Rate, Max: 0 ft/s
Linear Flow Rate, Min: 0 ft/s
Operating Pressure Note: Operating Pressure: 8.6 bar (125 psi) @ 21°C (70°F), 3.4 bar (50 psi) @ 100°C (212°F)
Operating Pressure, Max: 200 psi
Process Connection Size: 1 in
Process Connection Type: NPT Male
Process Temperature, Max: 121 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 8 GPM
Volumetric Flow Rate, Min: 4 GPM
Operating Temperature, Max: 66 °C
Operating Temperature, Min: 0 °C
Material Construction Option: N/A
