Length: 3 in
Accuracy: ± 5 %
Diameter: 1.05 in
Approvals: CE
Wire Gauge: 22 AWG
Adjustments: Potentiometer
Switch Type: SPST NO/NC, Selectable
Cable Length: 10 ft
Accuracy Note: ±5% of setpoint at constant temperature and flowrate
Response Time: 10 sec
Switch Rating: 1 A
Approvals Note: CE compliance: EN 61326 EMC EN 61010‐1 safety
Pipe Size, Max: 1.5 in
Pipe Size, Min: 0.75 in
Supply Voltage: 12 to 36 Vdc
Thermal Effects: 0.5%/°C
Cable Length Note: Max: 100 ft
Power Consumption: 70 mA
Supply Power Note: 12 to 36 Vdc @ 70 mA
Enclosure Material: PVDF
Response Time Note: 10 sec after initial 30 sec warm up
Media Compatibility: Gases
Additional Features 1:
Electrical Connection: 3/4 in NPT male Conduit with Screw Terminal block
Linear Flow Rate, Max: 90 ft/s
Linear Flow Rate, Min: 1 ft/s
Operating Pressure Note: Maximum Fluid Pressure: PP or PVDF: 150 psi @ 25°C (77°F) derated @ 1.667 psi per °C above 25°C (77°F)
Operating Pressure, Max: 150 psi
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 60 °C
Process Temperature, Min: 0 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -40 °C
