Display: No Display
Accuracy: ± 0.5 %
Linearity: ±0.01% rdg
Duty Cycle: 50 % ± 15 %
Sensor Type: Hall Effect
Bearing Type: N/A
Accuracy Note: ±0.5% over 10:1 turndown with 30cP fluid
Repeatability: ±0.1%
Amplitude Note: 1 to 40 Vp-p
Driving Method: 50 mA max resistive load
Supply Voltage: 10 to 28 Vdc
Viscosity Range: 200 cSt
Housing Material: Aluminum
Output Frequency: 0.5 to 2000 Hz
Electrical Output: Amplified Square Wave
Supply Power Note: 8 mA @ 12 Vdc,12 mA @ 24 Vdc
Supply Power Type: DC
Media Compatibility: Hydraulic Oil, Light Oil, Oil
Impedance Output Note: 40 Ω - analog switch and self-resetting fuse
Operating Pressure, Max: 5000 psi
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 85 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 60 GPM
Volumetric Flow Rate, Min: 0.5 GPM
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
