Width: 2.2 in
Height: 2.2 in
Length: 4.25 in
Accuracy: ± 1 %
Approvals: CE
Cable Length: 1 ft
Output Detail: Amplified Square Pulse, NPN Open Collector (load 30 mA maximum)
Pressure Type: Gauge
Response Time: 1 s
Supply Current: 2 mA
Supply Voltage: 5 to 24 Vdc
Viscosity Note: Calibrated 1 cSt, up to 50 cSt with field calibration
Viscosity Range: 1 to 50 cSt
Electrical Output: Amplified Square Pulse, NPN Open Collector
Materials, Wetted: 316 Stainless Steel, Polypropylene, PTFE, Sapphire, Zirconia
Supply Power Note: 5 to 24 Vdc @ 2 mA
Pressure Drop Note: Maximum Pressure Drop: 15 psi on size 2 units 20 psi on all other sizes
Pressure Drop, Max: 20 psi
Response Time Note: At 1 sec 10 to 90% of full scale, at 2 sec below 10% of full scale
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Process Temperature, Max: 60 °C
Volumetric Flow Rate, Max: 10 GPM
Volumetric Flow Rate, Min: 1 GPM
Material Construction Option: PVDF Body, with Temperature Sensor
