Weight: 26.5 lb
Accuracy: ± 0.2 %
Compliance: CE, RoHS 2
Media Type: Liquids
Density, Max: 3 g/cm³
Density, Min: 0.2 g/cm³
Display Type: LCD
Output Detail: Pulse Output: 0 to 10 kHz, ± 0.075% Full Scale Current Output: 4 to 20 mA, 0.005% Full Scale
Output Signal: Current, DC Pulse
Data Interface: RS485
Humidity Range: 5 to 95% RH
Supply Voltage: 18 to 36 Vdc
Density Accuracy: ± 0.002 g/cm³
Electrical Output: 4 to 20 mA, 0 to 10 kHz
Enclosure Ratings: IP65, NEMA Type 4X
Materials, Wetted: 304 Stainless Steel, 316L Stainless Steel
Supply Power Note: 18 to 36 Vdc, 85 to 265 Vac (-AC option), 15 W
Data Interface Note: RS485 (RTU Modbus®), HART® (-HART option)
Mass Flow Rate, Max: 45000 kg/h
Mass Flow Rate, Min: 2500 kg/h
Media Compatibility: Alcohol, Liquids, Oil, Water
Temperature Accuracy: ± 1 °C
Additional Features 1: Remote Mounted Display/Transmitter
Density Repeatability: ± 0.001 g/cm³
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Operating Pressure Note: 16 bar (230 psi), [Optional: 25 bar (360 psi), 40 bar (580 psi) and 63 bar (913.7 psi)]
Operating Pressure, Max: 230 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 2 in
Process Connection Type: JIS Flange
Stability Of Zero Point: 5 kg/h
Process Temperature, Max: 125 °C
Process Temperature, Min: -50 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -40 °C
