Width: 1.75 in
Height: 3.5 in
Length: 3 in
Accuracy: ± 3 %
Mounting: #4 Screw
Linearity: ±3%
Cable Length: 3 ft
Display Type: LCD
Output Detail: 0 to 5 Vdc, adjustable ±20% (typical)
Output Signal: Voltage
Repeatability: ±0.5%
Supply Current: 30 mA
Supply Voltage: 11.5 to 15 Vdc
Number of Digits: 3.5
Electrical Output: 0 to 5 Vdc
Materials, Wetted: Brass, FKM, Sapphire, Stainless Steel
Pressure Drop, Max: 3 inH₂O
Repeatability Note: ±0.5% FS from 50 to 100% of rated maximum flow for gas
Temperature Effect: ±0.2%/°C
Flow Characteristic: Gas
Media Compatibility: Gases
Electrical Connection: Four-Pin
Operating Pressure Note: 40 psi at 20°C (68°F)
Operating Pressure, Max: 40 psi
Process Connection Size: 1/4 in
Process Connection Type: Acetal Tube Fitting
Storage Temperature, Max: 70 °C
Storage Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 10 l/min
Volumetric Flow Rate, Min: 2 l/min
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
Material Construction Option: Brass
