Weight: 150 g
Accuracy: ± 0.5 %
Approvals: CE Conformity as per EMC Directive EN 61326-1: 2013 EN 50581: 2012
Materials: Ceramic
Cable Type: Insulated
Sensitivity: 75.0, 93.8 µm/mA
Cable Length: 5 m
Tip Diameter: 7.2 mm
Accuracy Note: 0 °C to + 45 °C : ±0,2 % from full scale (FS) Overall operating temperature range : ±0.5 % (FS) Deviation (DSL) from best fit straight line with nominal loop sensitivity in the temperature range of: 0 °C to +45 °C : ±25 µm Overall operating temperature range : ±75 µm
Output Detail: 4 - 20 mA, live-zero
Cable Diameter: 2.9 mm
Housing Length: 4.13 in
Supply Voltage: 24 Vdc
Loop Resistance: 250 Ω
Mounting Torque: 5 Nm
Transducer Type: Displacement Measurement
Housing Diameter: 0.315 in
Housing Material: Stainless Steel
Measurement Note: Eddy current Mesurment Axial Shaft Position
Measurement, Max: 60 mil
Measurement, Min: 0 mil
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP68, IP69
Power Consumption: 21 mA
Supply Power Note: +24 VDC (+12 VDC ... +32 VDC)
Frequency Response: Loop Frequency: DC to 0.8 Hz
Unthreaded Section: 15 mm
Wiring/Connector Table: Loop : white (+), black (-) Dynamic output: red (+), blue (-)
Integrated Cable Length: 0.5 dm
Process Connection Size: 3/8 in
Process Connection Type: UNF
Transmitter Body Length: 105 mm
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -55 °C
Operating Temperature, Max: 105 °C
Operating Temperature, Min: -40 °C
Water tight Proof Pressure: Transmitter tip: 25 bar
Compensated Temperature, Max: 27 °C
Compensated Temperature, Min: 18 °C
