CMRR: 85 dB
Width: 22.5 mm
Height: 110 mm
Length: 77 mm
Weight: 142 g
Mounting: DIN Rail Mount
Isolation: 700 V
Linearity: ±2°C
Materials: Plastic
Input Type: Thermocouple Type J
Output Value: Process
Output Detail: 0 to 10 V into 5 KΩ minimum resistive load
Output Signal: Voltage
Response Time: 1.5 s
Linearity Note: ±2°C (does not include thermocouple error)
Supply Voltage: 22 to 26 Vdc
Load Resistance: 0 to 500 Ω
Number of Inputs: 1
Supply Power Note: 22 to 26 Vdc (unregulated); 15 mA (models DRC-8920/21/40/41/42), 20 mA
Supply Power Type: DC
Open_Circuit Voltage: 13 V
Voltage Output Range: 0 to 10 V
Additional Features 1: Slim Housing Mounts on DIN Rail
Temperature Coefficient: Zero, 0.02°C/°C typical; reading. 0.015 °C/°C typical
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
Temperature Measurement Range: 0 to 500 °C
