Width: 192 mm
Height: 160 mm
Length: 103 mm
Weight: 1.4 kg
Scan Rate: Fixed, 2 channels/sec
Input Type: Thermocouple
Resolution: 1 °C or °F
Calibration: Calibration: NIST traceable (temperature),Resolution: 1°C or F,Thermistor: 0.1°C/0.2°F,Process: 9999, 999.9, 99.99, 9.999,Selectable Temperature Units: Celsius or Fahrenheit
Form factor: Wall Mount
Display Size: 20 mm (.78 in)
Display Type: 7 Digit LED
A/D Conversion: 20,000 count A/D converter; dual-slope integrating converter
Control Output: Open-Collector Output
Recording time: Displayed in hours, minutes and seconds,Format: HH.MM.SS
Supply Voltage: 120 Vac
Conversion Rate: 7 conversions per second
Input Type Note: J, K, T, E, R, S, B, Pt100 RTD and thermistor [2252 Ω @ 25°C (77°F)], 4 to 20 mA, 0 to 100 mV, 0 to 10 Vdc
Measuring Range: Thermocouple: Type J: -200 to 1190°C Type K: -170 to 1365°C Type T: -155 to 400°C Type E: -185 to 915°C Current: 1 to 30,000 counts Voltage: 1 to 30,000 counts
Number of Inputs: 1
Number of Relays: 7
Display Type Note: Red 7-segment LED display, 7 digits, 20 mm (0.8") high; negative polarity indication Over-Range Indication: “HELP” Display Test: Briefly indicates 8.8.8.8.8.8.8 on power-up
Enclosure Ratings: IP65
Supply Power Note: 120 Vac—60 Hz (standard) 220 Vac—50/60 Hz (optional) 8 to 15 Vdc @ 900 mA
Thermocouple Type: J, K, T, E, R, S, B, N
Enclosure Material: Polycarbonate
Number of Channels: 7
Cold Junction Error: 1°C (10 to 40°C)
Channel Display Time: Programmable from 1 to 999 seconds
Additional Features 1: dedicated_input
Temperature Sensor Type: N/A
Material Construction Option: N/A
Open Thermocouple Indication: "HELP" displayed
Retransmission/Analog Output: 7 Relays
Retransmission/Analog Output Note: SPST, 1 A @ 28 Vdc or 0.5 A @ 120 Vac
