Width: 89 mm
Height: 76 mm
Length: 51 mm
Weight: 255 g
Calibration: Internal controls, non interactive zero, span and linearity ± 10% range
Auto-Shutoff: 5 minutes, standard with NS option
Battery life: 2000 hr
Display Type: 4 digit LCD, Backlit display
Accuracy Note: ± 0.25% FS ± 1 least significant digit; linearity, hysteresis and repeatability combined
Pressure Type: Vacuum
Pressure, Max: -15 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 4x Full Scale or Maximum 10,000 psi
Shipping Weight: 454 g
Thermal Effects: ± 0.5% of span (typical), ± 1% of span (maximum) 0 to 82°C (32 to 180°F)
Display Type Note: 4 digit, LCD, 10.16 mm (0.4") digit height, 3 readings per second, nominal update rate
Enclosure Ratings: IP66
Materials, Wetted: Stainless Steel
Pressure Accuracy: ± 0.25 %
Supply Power Note: Battery Note:2 “AA” alkaline included, approximately 2000 hr (150 to 1500 hr for DPG5600 models; low battery indicator
Supply Power Type: Battery
Enclosure Material: ABS
Number of Batteries: 2
Battery Size and Type: Alkaline AA
Display Segment Height: 0.4 in
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 70 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 95 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
