OMEGA DPG110 ເຄື່ອງວັດຄວາມດັນດິຈິຕອນມີກອງຮັບກັນທີ່ທົນທານ (Gauge, 100 psi, NPT Male, 1/4 in)

Width: 63 mm

Height: 101 mm

Length: 44 mm

Weight: 0.16 kg

Stability: (1 Year): ± 0.25% FS typical

Auto-Shutoff: 1 hour

Battery life: 100 hr

Accuracy Note: ± 0.5% BFSL (includes non-linearity, hysteresis, repeatability)

Pressure Type: Gauge

Pressure, Max: 100 psi

Pressure, Min: -14 psi

Accuracy Class: > 0.25%

Burst Pressure: 4x Full Scale

Proof Pressure: 2x Full Scale

Pressure Cycles: >100 million cycles

Number of Digits: 3.5

Materials, Wetted: Stainless Steel

Pressure Accuracy: ± 0.5 %

Supply Power Type: Battery

Sample/Display Rate: 3 samples per second

Thermal Span Effect: <± 1.5% FS

Thermal Zero Effect: <± 1.5% FS

Battery Size and Type: Alkaline 9V

Process Connection Size: 1/4 in

Process Connection Type: NPT Male

Process Temperature, Max: 55 °C

Process Temperature, Min: 0 °C

Storage Temperature, Max: 65 °C

Storage Temperature, Min: -40 °C

Operating Temperature, Max: 55 °C

Operating Temperature, Min: 0 °C
