CMRR: 120 dB
NMRR: 60 dB
Width: 3.78 in
Height: 1.89 in
Length: 6.5 in
Weight: 574 g
Accuracy: ± 0.005 %
Mounting: Panel
Polarity: Unipolar/Bipolar, programmable
Materials: Polycarbonate
Input Type: Single Ended, Strain
Resolution: 15-bit
Form factor: 1/8 DIN
Display Note: Red 6-digit, 14-segment, 13.7 mm (0.54") high; 4 alarm indicators
Display Type: LED
Reading Rate: 3/s or 13/s, 60 Hz; 3/s or 12/s, 50 Hz
Warm Up Time: 50 min
Output Detail: Analog Output
Output Signal: Current, Voltage
Sampling Rate: 13 Hz (13 updates/second)
Step Response: 1 s to 99.9%
Data Interface: N/A
Supply Voltage: 115 Vac
Span Adjustment: 0.00001 to 500,000, programmable
Input Range Note: 0 to 100 mV, 0 to 1V, 0 to 5V, 1 to 5V, 0 to 10V, 0 to 100V, ± 50 mV, ± 500 mV, ± 5V, ± 50V, 0 to 20 mA, 4 to 20 mA
Measurement Type: Strain
Number of Digits: 6
Number of Inputs: 1
Number of Relays: N/A
SetPoint Outputs: 4 Isolated Open Collector; Rated 150 mA at 1V Sink, 30V Open
Cutout Dimensions: 1.772 x 3.622 in
Offset Adjustment: 0 to 999999 or 0 to - 99999 programmable
Power Consumption: 10 W
Relative Humidity: 95% RH non-condensing
Sensor Excitation: 10 V at 30 mA; 24V at 25 mA
Supply Power Note: 115 Vac, 49 to 400 Hz
Supply Power Type: AC
Common Mode Voltage: 1500 Vp per HV test
Input Configuration: Front panel buttons or via your computer
Internal Resolution: 15 bit
Power Consumption Note: 6 W Nominal, 10 W
Sensor Break Protection: Up-scale or down-scale, programmable
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
Analog-to-Digital Technique: Dual slope
Span Temperature Coefficient: ± 20 ppm
