Width: 51 mm
Height: 73 mm
Length: 96 mm
Weight: 510 g
Accuracy: ± 0.15 %
Bandwidth: 10 Hz (-3 dB)
Isolation: AC Line: 1100 Vrms, 60 pF, Input to Output: 700 Vdc and 60 pF
Linearity: ± 0.005%
Gain Range: 200 to 2000
Input Type: Voltage
Capacitance: 60 pF
Input Range: 5 to 50 mV
Supply Power: 120 Vac
Output Signal: Voltage
Response Time: 35 ms
Current Output: 5 mA
Tare Adjustment: -3 to 25 mV
Input Resistance: 1000 MΩ
Electrical Output: 0 to 10 Vdc
Supply Power Note: 115 Vac ± 10 Vac standard or 220 Vac ± 10% 50/60 Hz optional
Supply Power Type: AC
Compliance Voltage: 20 Vdc
Response Time Note: 10 to 90% = 35 ms
Long Term Stability: Temperature: 0.005%/°C
Excitation Voltage Note: Voltage Range: 5 to 10 Vdc Current Output: 120 mA max Line and Load Regulation: 0.02% max Output Noise: 1 mVrms max (120 Hz) Temp Coefficient: 60 ppm @ 10V, 100 ppm max
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -25 °C
Zero Setting Adjustable Range: 0 to 2 V
