Loops: Control Loops : 2
Width: 216 mm
Filter: Averages 2 to 64 input readings
Height: 89 mm
Keypad: 20-key membrane, numeric and specific functions
Length: 368 mm
Tuning: Autotune, PID, PID zones
Weight: 4 kg
Accuracy: Selectable
RTD Type: 4-lead differential With 6-Pin DIN Connector
Approvals: CE Mark
Baud Rate: 9600 to 57600
Isolation: Sensor inputs optically isolated from other circuits but not each other
Input Type: Thermocouple, RTD, Thermistor
Resolution: Sensor dependent, refer to input specifications table
Form factor: Benchtop
Control Type: Manual Heater Output, Open Loop, PID Control
Display Size: 5.5 mm Digits
Display Type: LCD
Accuracy Note: PTC RTD (0 to 500 Ω : Range) : ± 0.004 Ω, ± 0.01 % of rdg PTC RTD (0 to 5000 Ω : Range) : ± 0.004 Ω, ± 0.02 % of rdg NTC RTD (0 to 7500 Ω : Range) : ± 0.1 Ω, ± 0.04 % of rdg Thermocouple (± 25 mV) : ± 1 µV,± 0.05 % of rdg Thermocouple (± 50 mV) : ± 1 µV,± 0.05 % of rdg
Output Detail: 2 Heater output
Output Signal: None
Sampling Rate: 10 Hz (10 updates/second)
A/D Conversion: 24-bit
Control Output: Heater
Data Interface: RS232
Supply Voltage: 100 to 240 Vac
Input Type Note: Temperature, sensor units Input Configuration: Each input is factory configured for either diode/RTD or thermocouple
Measurement Type: Temperature
Number of Inputs: 2
Software Support: LabVIEWTM driver; consult factory for availability
Update Rate, Max: 10 rdg/s on each input (except 5 rdg/s on input A when configured as thermocouple)
Display Type Note: Display: 2-line, 20-character, liquid crystal display with 5.5 mm (0.216”) character height Display Update Rate: 2 rdg/s Other Displays: Setpoint, heater range, and heater output; user selected
Power Consumption: 6 W
Supply Power Note: Standard 120 Vac, optional 240 Vac, 6%, -10%, 50 or 60 Hz, 85 VA
Supply Power Type: AC
Thermocouple Type: E, K, T, AuFe 0.07% vs Cr, AuFe 0.03% vs Cr
Interface Features: IEEE-488 Interface Features: SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT0, C0, E1
Sampling Rate Note: To 10 rdg/s on each input
Settable Parameters: Curve Entry, Keypad Lock-out
Display Annunciators: Autotune, Control input, Remote
Electrical Connection: Ceramic Isothermal Block
Heater Output Display: Percentage of full power or current
Digital Connector Type: 9 pin Sub-D
Control Characteristics: PID Control Settings: Proportional (Gain): 0 to 1000 with 0.1 setting resolution Integral (Reset): 1 to 1000 (1000/s) with 0.1 setting resolution Derivative (Rate): 1 to 200% with 1% resolution Manual Output: 0 to 100% with 0.01% setting resolution Zone Control: 10 temperature zones with P, I, D, manual heater out, and heater range Setpoint Ramping: 0.1 K/min to 100 K/min Safety Limits: Curve temperature, power up heater off, short circuit protection
Display Measuring Units: °C, K, mV, V
Temp Display Resolution: 0.001° from 0 to 99.999°, 0.01° from 100 to 999.99°, 0.1° above 1000°
Heater Output Resolution: 0.01
Number of Control Outputs: 2
Operating Temperature, Max: 35 °C
Operating Temperature, Min: 15 °C
Sensor Input Configuration: Measurement Type: 4-lead differential Excitation: Constant current with current reversal for RTDs Supported Sensors: Diodes, silicon, GaAlAs; RTDs, 100 Ω Platinum, 1000 Ω Platinum, germanium, carbon-glass, CernoxTM, and RoxTM Standard Curves: CY7 and CY670, PT-100, PT-1000, RX-102A, RX-202A Input Connector: 6-pin DIN
Setpoint Setting Resolution: Same as display resolution (actual resolution is sensor dependent)
Front Panel Display Readings: 1 to 4
Sensor Units Display Resolution: Sensor dependent up to 5 digits
