Width: 96 mm
Height: 96 mm
Length: 15.8 mm
Weight: 425 g
Accuracy: ± 0.25 %
Input Type: Thermocouple, RTD, Thermistor
Form factor: 1/4 DIN
Display Type: 4 Digit LED
Accuracy Note: ± 0.25% span, ± 1 least significant digit
Memory Backup: Non-Volatile
Output Detail: Current;Current: 4 to 20 mA
Output Signal: Current
Control Output: Analog Current
Data Interface: RS485 Modbus
Supply Voltage: 100 to 240 Vac
Measuring Range: Type B: 100 to 1800°C Type S: 0 to 1700°C Type R: 0 to 1700°C Type N: -200 to 1300°C Type E: 0 to 600°C Type T: -20 to 400°C and -200 to 400°C Type J: -20 to 400°C and -100 to 850°C Type K: -200 to 1300°C and -200 to 500°C Type L: -200 to 500°C Type U: -200 to 800°C Pt100Ω RTD: 0 to 100°C, -20 to 500°C, -200 to 600°C
Measurement Type: Temperature
Number of Inputs: 1
Cutout Dimensions: 92 × 92 mm
Display Type Note: Two 4-digit, 7-segment, LEDs PV: Red, 19 mm H (0.75") SV: Green, 12.7 mm H (0.5")
Enclosure Ratings: IP66
Supply Power Note: 100 to 240 Vac, 50/60 Hz
Supply Power Type: AC
Depth Behind Panel: 79.2 mm
Number of Control Outputs: 1
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
