Accuracy: ± 0.25 %
Stability: 0.4% RO
Vibration: (5-2000 Hz): 0.04% RO/G (Max.)
Accuracy Note: Combined Effects Non-Linearity, Hysteresis and Repeatability: 0.25% RO (Max.)
Output Signal: Voltage
Pressure Type: Absolute
Pressure, Max: 600 inHg
Pressure, Min: 0 inHg
Accuracy Class: 0.1% to 0.25%
Stability Note: Thermal Zero Stability: 0.4% RO (Max.) Thermal Sensitivity Stability: 0.3% RO (Max.)
Supply Voltage: 28 Vdc ± 4 Vdc
Thermal Effect: 0.0020/°F (0.0036/°C) Max.
Electrical Output: 0 to 5 V
Zero/Balance Error: ± 10% Adjustable (Min.)
Electrical Connection: MIL-26482-I 10-6P
Electrical Output Note: 5 VDC ± 0.25% (± 10% Adjustable) Short Circuit Protected
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Compensated Temperature, Max: 150 °F
Compensated Temperature, Min: -25 °F
Thermal Effect on Zero error, Max: 0.0015/°F (0.0027%/°C) Max.
