Phased array channels:
16:64PR: 64
16:128PR/32:128PR: 128
Number of pulsers:
16:64PR/16:128PR: 16 consecutive elements
32:128PR: 32 consecutive elements
Conventional UT channels:
4 dedicated UT channels
(8 connectors for pulse-echo and pitch-catch configurations support)
Data acquisition rate:
Up to 30 MB/s (1 FOCUS PX)
Up to 60 MB/s (2 to 4 FOCUS PX)
Acquisition speed: Up to 20000 12-bit A-scans/second of 750 points each
Amplitude resolution: 8-bit / 12-bit
Maximum number of A-scan samples: 16380
Real-time data compression: 1 to 2000 ratio
Rectification: FW, HW+, HW–, and RF
Filtering: Digital band-pass, high-pass and low-pass filters
Voltage:
PA: 4 V, 9 V, 20 V, 40 V, 80 V, and 115 V
UT: 50 V, 100 V, and 190 V
Gain:
PA : 80 dB (46 dB analog + 34 dB digital)
UT : 120 dB (digital)
Pulse width:
PA : 30 ns to 500 ns (steps of 2.5 ns)
UT : 30 ns to 1000 ns (steps of 2.5 ns)
Bandwidth (-3 dB):
PA : 0.6 MHz to 17.8 MHz
UT : 0.25 MHz to 28 MHz
Number of beams: Up to 1024
Pulse repetition frequency (PRF): 1 Hz to 20 kHz
Real-time averaging:
PA : 1, 2, 4, 8, 16
UT : 1, 2, 4, 8, 16, 32, 64
Number of gates: 4 for detection; 1 for synchronization
Encoder: 2 axes (quadrature, clock direction)
Network interface: 1000BASE-T
Size (W x H x D) With bumpers: 30.7 cm × 13.5 cm × 23.6 cm (12 in. × 5.3 in. × 9.3 in.)
Size (W x H x D) Without bumpers: 27.6 cm × 9.2 cm × 23.1 cm (10.9 in. × 3.6 in. × 9.1 in.)
Weight With bumpers: 4.8 kg (10.5 lb)
Weight Without bumpers: 4.2 kg (9.2 lb)
IP rating: IP65
