NXP MPC8321ECVRADDCA ຊິບປະມຸງ - MPU PowerQUICC, 32 Bit Power Architecture SoC, 266MHz e300, QE, PCI, USB2.0, DDR1/2, SEC, -40-105C

Core: e300c2

I/O Voltage: 1.8 V, 2.5 V, 3.3 V

Memory Type: DDR1 SDRAM, DDR2 SDRAM

Unit Weight: 4.374 g

Data Bus Width: 32 bit

Interface Type: Ethernet, GPIO, I2C, SPI, UART, USB

Mounting Style: SMD/SMT

Number of Cores: 1 Core

Watchdog Timers: No Watchdog Timer

Processor Series: PowerQUICC II Pro

Moisture Sensitive: Yes

L1 Cache Data Memory: 16 kB

Maximum Clock Frequency: 266 MHz

Operating Supply Voltage: 1 V

Number of Timers/Counters: 4 Timer

L1 Cache Instruction Memory: 16 kB

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
