Width: 6.4 mm
Height: 3.4 mm
Length: 19 mm
Shutdown: No Shutdown
Technology: Bipolar
Output Type: Open Collector
Supply Type: Single, Dual
Unit Weight: 1.620 g
Response Time: 1.3 us
Mounting Style: Through Hole
Comparator Type: General Purpose with Reference
Voltage Gain dB: 106 dB
Reference Voltage: No
Number of Channels: 4 Channel
Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Supply Voltage - Max: 36 V
Supply Voltage - Min: 2 V
Pd - Power Dissipation: 570 mW
Ib - Input Bias Current: 250 nA
Operating Supply Current: 2 mA
Operating Supply Voltage: 36 V
Vcm - Common Mode Voltage: Negative Rail to Positive Rail 3.5 V
Ios - Input Offset Current: 50 nA
Output Current per Channel: 16 mA
Vos - Input Offset Voltage: 7 mV
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 1 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
