Voltage: 1200V
Current: 360A
Power: 12000W
Min operating voltage: 20V@36A/ 20V@360A
CC mode
Range: 0~36A/ 0~360A
Setting Resolution: 1mA/ 10mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
CV mode
Range: 0~120V/ 0~1200V
Setting Resolution: 10mV/ 100mV
Setting Accuracy: (23±5℃) 0.05%+0.05%F.S.
CP mode
Range: 0~12000W
Setting Resolution: 0.1W
Setting Accuracy (23±5℃): 0.5%+0.5%F.S
CR mode
Range: 0.07Ω~333Ω / 1.3Ω~3333Ω
Setting Resolution: 16 bits
Setting Accuracy (23±5℃): 0.35%+9.4mS / 0.35%+0.94mS
Slew Rate
Current: 6-360A/ms / 360-18000A/ms
Voltage: 8~400V/ms 400~4000V/ms
Power: 6-360A/ms / 360-18000A/ms
Resistance: 6-360A/ms / 360-18000A/ms
Voltage Measurement
Range: 0~120V/ 0~1200V
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Current Measurement
Range: 0~36A / 0~360A
Readback Accuracy (23±5℃):0.05%+0.05%F.S.
Power Measurement
Range: 0~12000W
Readback Accuracy (23±5℃): 0.5%+0.5%F.S.
Interface: LAN/RS232/CAN
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Sampling Frequency: 25Hz
Communication Response Time: ≤10ms
Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Net weight: Approx. 108kg
Dimension: 12U, 530.0(H)*482.0(W)with handle*612.0(D)mm
