Voltage: 150V
Current: 20A
Power: 150W
Min. Operating Voltage: 0.5V@2A, 1V@20A
Channels: 12
CV Mode
Range: 0~15V, 0~150V
Setting Resolution: 1mV, 10mV
Setting Accuracy (23±5℃): 0.025%+0.025%F.S
Readback Accuracy (23±5℃): 0.025%+0.025%F.S
CC Mode
Range: 0~2A, 0~20A
Setting Resolution: 0.1mA , 1mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
Readback Resolution: 10μA, 0.1mA
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
CP Mode
Range: 15W, 150W
Setting Resolution: 1mW, 10mW
Setting Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Resolution: 1mW, 10mW
Readback Accuracy (23±5℃): 0.1%+0.1%F.S
CR Mode
Range: 0.5Ω~30000Ω, 0.25Ω~3000Ω
Setting Resolution: 0.1Ω, 0.01Ω
Setting Accuracy (23±5℃): (Vin/Rset)*0.1+0.1%IF.S.
Slew Rate
Current: 0.1~130A/ms, 0.1~1600A/ms
Power: 0.1~130A/ms, 0.1~1600A/ms
Resistance: 0.1~130A/ms, 0.1~1600A/ms
Dynamic Mode (CCD)
T1&T2: 0.016ms~60000ms/0.016s~60000s
Resolution: 1μs/1ms
Rise/Fall Slew Rate: 0.1~130A/ms, 0.1~1600A/ms
Others
Protection: OVP/OCP/OPP/OTP/RV
Interface: LAN/RS232/RS485
Communication Protocol: Modbus-RTU protocol, SCPI protocol
Communication Response Time: ≤5ms
AC Input: Single phase, 100~240V AC, frequency 47Hz~63Hz, current≤1A@220V, current≤2A@110V
Net Weight: Approx.18kg
Dimension: 3U, 132.0(H)*482.0(W)with handle*495.0(D)mm
