Voltage: 150V
Current: 40A
Power: 300W
Min. Operating Voltage: 0.5V@4A, 1V@40A
Channels: 6
CV Mode
Range: 0~15V, 0~150V
Setting Resolution: 1mV, 10mV
Setting Accuracy (23±5℃): 0.025%+0.025%F.S
Readback Resolution: 0.1mV, 1mV
Readback Accuracy (23±5℃): 0.025%+0.025%F.S
CC Mode
Range: 0~4A, 0~40A
Setting Resolution: 0.1mA, 1mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S
Readback Resolution: 10μA, 0.1mA
Readback Accuracy (23±5℃): 0.05%+0.05%F.S
CP Mode
Range: 30W, 300W
Setting Resolution: 1mW, 10mW
Setting Accuracy (23±5℃): 0.1%+0.1%F.S
Readback Resolution: 0.1mW, 1mW
Readback Accuracy (23±5℃): 0.1%+0.1%F.S
CR Mode
Range: 1Ω~15000Ω, 0.1Ω~1500Ω
Setting Resolution: 1Ω, 0.1Ω
Setting Accuracy (23±5℃): (Vin/Rset)*0.1+0.1%IF.S
Slew Rate
Current: 0.1~260A/ms, 0.1~3200A/ms
Power: 0.1~260A/ms, 0.1~3200A/ms
Resistance: 0.1~260A/ms, 0.1~3200A/ms
Dynamic Mode (CCD)
T1&T2:0.016ms~60000ms/0.016s~60000s
Resolution: 1μs/1ms
Rise/Fall Slew Rate: 0.1~260A/ms, 0.1~3200A/ms
Others
Protection: OVP/OCP/OPP/OTP/RV
Interface: LAN/RS232/RS485
Communication Protocol: Modbus-RTU protocol, SCPI protocol, TCP/IP, UDP protocol
Communication Response Time: ≤5ms
AC Input: Single phase, 100~240V AC, frequency 47Hz~63Hz, current≤1A@220V, current≤2A@110V
Net Weight: Approx.18kg
Dimension: 3U, 132.0(H)*482.0(W)with handle*501.0(D)mm
