Voltage: 60V/CH
Current: 15A/CH
Power: 600W/CH
Channels: 4CH
CV Mode
Range: 0~60V
Setting Resolution: 1mV
Setting Accuracy (23±5℃): 0.05%+0.1%F.S
Setting Temperature Coefficient (0-40℃): 50ppm /℃
Readback Resolution: 1mV
Readback Accuracy (23±5℃): 0.05%+0.1%F.S.
CC Mode
Range: 0~15A
Setting Resolution: 1mA
Setting Accuracy (23±5℃): 0.1%+0.1%F.S
Setting Temperature Coefficient (0-40℃): 50ppm /℃
Readback Resolution: 1mA
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Temperature Coefficient: 50ppm/℃
Voltage Ripple(20Hz-20MHz): 250mVp-p, 20mVrms
Load Regulation: ≤0.03% (Voltage) / ≤0.05%(Current)
Line Regulation: ≤0.015% (Voltage) / ≤0.05%(Current)
Interface: RS232/LAN
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Temperature: Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 10kg
Dimension: 2U, 88.0(H)*214.0(W)*546.0(D)mm
