Voltage: 0～1500V
Current: -25A～25A
Resistance: 0.6Ω~12kΩ
Power: -12kW～+12kW
Constant Voltage Mode
Range: 0～1500V
Setting Resolution: 100mV
Setting Accuracy (23±5℃):0.02%+0.02%F.S.
Readback Resolution: 100mV
Readback Accuracy (23±5℃): 0.02%+0.02%F.S.
Voltage Reple（Vpp）: ≤1300mV
Voltage Riple（Vrms）: ≤300mV
Temperature Coefficient:≤50ppm/℃
Constant Current Mode
Range: -25A～25A
Setting Resolution: 1mA
Readback Accuracy (23±5℃):0.1%+0.1%F.S.
Readback Resolution: 1mA
Readback Accuracy(23±5℃): 0.1%+0.1%F.S.
Temperature Coefficient: ≤100ppm/℃
Constant Power Mode
Range: -12kW～+12kW
Setting Resolution: 1W
Readback Accuracy (23±5℃): 0.5%F.S.
Readback Resolution: 1W
Readback Accuracy(23±5℃):0.5%F.S.
Constant Resistance Mode
Range :0.6Ω~12kΩ
Setting Resolution: 0.01Ω
Readback Accuracy (23±5℃): Vin/Rset*0.01%+0.2% I.F.S
Line Regulation
Voltage: ≤0.01%F.S.
Current: ≤0.05%F.S.
Load Regulation
Voltage: ≤0.02%F.S.
Current: ≤0.05%F.S
AC Input
Input: Three phase , Please refer to the voltage mark at the rear panel.
Efficiency: 93%（typical）
Power Factor: 0.99（typical）
Operating Environment
Temp.specification: Operating Temp.：0℃~ 40℃；Storage Temp.：-20℃~ 70℃
Environment Altitude:＜2000m；Relative Humidity：5% ~ 90%（non condensing）；Air Pressure：80kPa ~110kPa
Dimension（mm:） 132.5(H)*482.0(W)*752(D), include the protective cover
Net weight: ≈18kg
