Output power: 9 kVA
AC/DC mode: AC, ACDC
AC output:
+ Voltage setting range:
Phase voltage: 0.0 V to 160.0 V/0.0 V to 320.0 V; 0.0 Vp-p to 454.0 Vp-p / 0.0 Vp-p to 908.0 Vp-p (arbitrary waveform). All-phase common setting for balanced mode. Each phase setting for unbalanced mode
Line to line voltage: 0.0 V to 277.2 V/0.0 V to 554.2 V
Resolution: Only for balanced mode and sine wave; Phase voltage: 0.1 V, line to line: 0.2 V
+ Max. current: 30 A/15 A
+ Max. peak current: 4 times value of maximum current
+ Load power factor range: 0 to 1 (lead or lag, at 45 Hz to 65 Hz)
+ Frequency setting range, output waveform: 40.00 Hz to 550.00 Hz (AC mode), 1.00 Hz to 550.00 Hz (ACDC mode), resolution: 0.01 Hz, waveform: sine, arbitrary (16 types), clipped Sine (3 types)
+ Output voltage stability : Line regulation: within ±0.15%, load regulation: within ±0.15 V/±0.3 V (45 Hz to 65 Hz), within ±0.5 V/±1.0 V (40 Hz to 550 Hz) (phase voltage)
+ Output voltage distortion factor: 0.5% or less (40 Hz to 550 Hz, 50% or more of rated output voltage, maximum output current or below, AC mode or ACDC mode) (phase voltage)
Measurement function:
+ Voltage: RMS value (rms), DC average (avg) (only single-phase models), peak value (pk)
+ Current: RMS value (rms), DC average (avg) (only single-phase models), peak value (pk), peak hold value
+ Power: Effective (W), apparent (VA), reactive (var) (option)
+ Others: Load power factor (option), load crest factor (option), synchronization frequency, harmonic current(option), CO2 emissions (excluding 24 kVA and 36 kVA model)...
Power input (specified on order): AC100 V to 230 V ±10%, 3P3W AC200 V to 220 V ±15% or 3P4W AC380 V ±15%; 50 Hz/60 Hz ±2 Hz
Efficiency: 77% or more (typ., at AC200 V input)
Power consumption (maximum): 13.5 kVA
Weight (approx.): 125 kg
Dimensions (W×H×D): 430 × 1021 × 562 mm
