Output
Maximum output voltage:
±150V range (rated resistance load 200Ω)
±150V range (rated resistance load 450Ω)
+250V range (rated resistance load 1,250Ω)
-250V range (rated resistance load 1,250Ω)
Rated output current: 0.5Arms (±150V range, rated resistance load 200Ω)
Output power: Constant voltage (CV)
Output polarity: In-phase or reversed phase (toggled with the panel switch)
Characteristics of small amplitude frequency:
+ DC to 100kHz, ±0.5 dB
+ 100kHz to 2MHz, +1, -3 dB
+ Conditions: Output amplitude 20 Vrms, reference 1 kHz
Gain setting:
+ Fixed: ×1, ×10, ×20, ×50
+ Variable: ×1 (CAL) to ×3, consecutive
+ The set gain equals to (Fixed × Variable).
Slew rate: 500V/μs
Output DC offset: Adjustment range: ±0.5V or more (input terminal short circuit)
Output DC bias: ±200V or more
Allows turning on/off by the front panel switch.
Output impedance: 0.5Ω + 1.5μH or less (typ.)
Output terminal: BNC connector (front panel), Lo side grounded to the cabinet
Monitor output: 1/100 of output voltage, in-phase
Monitor meter: Displays output voltage or current (toggled with the switch)
Output on/off: Front panel switch or external control input
Input
Maximum input voltage: ±10V
Number of terminals: 2 (A input: Front panel, B input: Rear panel)
(Input type may be A input, B input, or both A input and B input.)
Input terminals: BNC connector, Lo side grounded to the cabinet
Input impedance: 5Ω and 10kΩ, switchable
Miscellaneous
Protection function: Output overcurrent, output overvoltage, power section failure, abnormal internal temperature
External control input/output: 2 (A input: Front panel, B input: Rear panel)
(Input type may be A input, B input, or both A input and B input.)
Settings at power-on: Settings power-on made by dip switches on the rear panel (10 settings)
Power input: AC100V to 230V ±10% (at 250V or less), 50Hz/60Hz ±2Hz
Power consumption: 350VA or less
Operating temperature and humidity: 0 to +40°C, 5 to 85%RH
(Absolute humidity 1 to 25g/m3, no condensation)
Dimensions (mm): 258(W)×132.5(H)×390(D) (not including protrusions)
Weight: Approx. 7kg
