NEWLAND NVH220 ເຄື່ອງສະແກນມືຖືອຸດສາຫະກໍາ (35mm-210mm)
Image Sensor: 1280 × 960 CMOS
Illumination
Direct: white & red light LED;
Diffuse: Ring of blue LEDs;
LED 532nm
Symbologies
2D: QR Code, PDF417, Micro QR, Data Matrix, AZTEC.1D:EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128, Code93, Code11, COOP25,
GS1-128(UCC/EAN-128), ITF-6, ITF-14, AIM128, ISBT128, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, MSI Plessey, Code 39, Plessey, Deutsche 14, Deutsche 12.
Resolution: ≥3mil
Typical Depth of Field
EAN-13(13mil) : 25mm-160mm
Code 39(5mil) : 40mm-100mm
Code 39(20mil) : 35mm-210mm
Data Matrix(10mil) : 0mm-125mm
QR Code(20mil) : 20mm-180mm
Scan Angle
Roll: 360°, Pitch: ±50°, Skew: ±50°
Min. Symbol Contrast: 20%
Physical
Dimensions (L×W×H): 67(W)×86(D)×170(H) mm
Weight: 165g
Notification: Beep, LED indicator, Vibrator
Current
operating(typical) : 320mA
operating(max.) : 480mA
Interfaces: USB, RS232, PS/2
Environmental
Operating Temperature: -20°C to 50°C(-4°F to 122°F)
Storage Temperature: -40°C to 70°C(-40°F to 158°F)
Humidity: 5% to 95% (non-condensing)
ESD: ±16 KV (air discharge); ±8 KV (direct discharge)
Drop: 1.8m
Sealing: IP64
Certifications: FCC, CE, ROHS, IEC62471, BIS, KC
