Data Capture
1D: All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey.
2D: All major 2D symbologies, including PDF417, QR Code, Data Matrix, Aztec, Maxicode.
Image Sensor: CMOS 1280 x 800
Aiming: Green LED
Illumination: Red LED (625±10 nm) / White LED
Scan Modes: Trigger (Level, Pulse), Sense, Continuous Mode
Scan Rate: 60 frames per second
Depth of Field EAN 13 (13mil): 45-510mm
Depth of Field Code 39 (5mil): 75-220mm
Depth of Field PDF417 (6.67mil): 70-215mm
Depth of Field DataMatrix (10mil): 50-220mm
Depth of Field QR (15mil): 20-330mm
Field of View Horizontal: 39°
Field of View Vertical: 24°
Scan Angle Roll: 360°
Scan Angle Pitch: ±55°
Scan Angle Skew: ±55°
Minimal Print Contrast: 25%
Performance
Processor :1GHz, X1500
Physical
Buttons: Trigger
Current @ 5VDC Operating: 238.2mA (typical), 260.5mA (max.)
Current @ 5VDC Standby: 71.3mA
Dimensions (mm): 113.5(W) × 73.3(D) × 159.0(H)
Input Voltage: 5VDC ± 5%
Interfaces: RS-232, USB
Material: PC, ABS
Notifications: Beep, LED indicator
Power Consumption: 1289.6mW (typical)
Power Supply Input: DC5V, 1.5A
Power Supply Output: AC100~240V, 50~60Hz
Weight: 162g
Environmental
Ambient Light: 0 ~ 100000 lux (natural light)
