General
Dimensions: 4.05 in x 7.67 in x 2.16 in (10.3 cm x 19.5 cm x 5.5 cm)
Weight: 1.68 lbs. (0.77 kg)
Battery: Rechargeable lithium-ion battery pack (7.2 V, 6.4 A, 46 Wh)
Battery life: Typical operating life is 3-4 hours; Typical charge time is 3 hours
Display: 5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)
Host Interfaces: RJ-45 and SFP Analysis ports
RJ-45 Cable Test and Management Port
USB Type-A Port and USB Type-C On-the-Go Port
SMA Connector (for External Directional Antenna)
SD Card Port: Supports Micro SD card storage – up to 64GB supported
Memory: Approximately 8 GB available for storing test results and user applications
Charging: USB Type-C 45-W adapter: 100-240 Vac, 50-60 Hz; DC Output Power 15 V (3 A)
RJ-45: 802.3at PoE (25W) or higher
Media Access: Copper: 10M/100M/1G/2.5G/5G/10G
Fiber SFP Adapters: 1G/10GBASE-X
Supported IEEE Standards: Wired: 802.3/ab/ae/an/bz/i/u/z Wi-Fi: 802.11a/b/g/n/ac
PoE: 802.3af/at/bt, Class 0-8 and UPOE
Cable Test: Pair lengths, opens, shorts, split-pairs, crossed, straight through, and WireView ID
NPT Reflector
Supporting Operating Systems: Windows® 8.1, Windows® 10, Windows® 2008-R2, Windows® 2012, Windows® 2012-R2, Windows® 2016 and Windows® 2019
Processor: 1 GHz or better CPU
RAM: 1 GB or more
Hard Disk: 1 GB available space
Network Interface: Ethernet and/or Wi-Fi
Includes: (1) EXG-200 mainframe with Li-ION battery, G3-PWRADAPTER, SFP+MR-10G850, Inline RJ-45 coupler, WireView wire mapper #1, Quick Start Guide, and small softcase.
