General
Dimensions: 4.98 in x 7.68 in x 1.65 in (102 mm x 196 mm x 42 mm)
Weight: 1.05 lbs. (0.48 kg)
Battery: Rechargeable lithium-ion battery pack (3.63 V, 9.75 A, 35.39 Wh)
Battery Life: Typical operating life is 10 hours (Battery life from full charge varies depending on the feature being used); Typical charge time is 3-4 hours.
Display: 5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)
Host Interface:
2 USB Type-A Ports
USB Type-C Power and On-the-Go Port
RP-SMA External Antenna Port
Memory: Approximately 8 GB available for storing test results and user applications
Charging: USB Type-C 45-W adapter: AC Input Power 100-240 V, 50-60 Hz; DC Output Power 15V (3A)
Wireless
AirCheck G3 has two internal Wi-Fi Radios:
Testing – 2×2 Tri-band 802.11ax wireless radio (IEEE 802.11a/b/g/n/ac/ax compliant)
Management – 1×1 Dual-band 802.11ac Wave 2 + Bluetooth 5.0 and BLE wireless radio (IEEE 802.11a/b/ g/n/ac compliant)
Specification Compliance: IEEE 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax
Wi-Fi Connectivity: 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax
Operating Frequencies: Frequencies of channels received and transmitted:
2.4 GHz band: 2.412 to 2.484 GHz (channel 1 to channel 14)
5 GHz band: 5.170 to 5.320 GHz, 5.500 to 5.700 GHz, 5.745 to 5.825 GHz (channel 36 to channel 165)
6 GHz band: 5.925 to 7.125 GHz (channel 1 to channel 233)
Antennas
Internal Wi-Fi Antennas: Minimum gain 2.0 dBi peak in the 2.4 GHz band, 1.5 dBi peak in the 5 GHz band, and 2.7 dBi peak in the 6 GHz band.
External Directional Antenna: Antenna, frequency range 2.4 to 2.5 GHz, 4.9 to 5.9 GHz. and 6.0 to 7.1 GHz
Minimum gain 6.4 dBi peak in the 2.4 GHz band, 8.9 dBi peak in the 5 GHz band, and 8.6 dBi peak in the 6 GHz band.
Environmental
Operating Temperature: 32°F to 113°F (0°C to +45°C)
Operating relative humidity (% RH without condensation):
90% (50°F to 95°F; 10°C to 35°C)
75% (95°F to 113°F; 35°C to 45°C)
Storage temperature: -4°F to 140°F (-20°C to +60°C)
Shock and vibration: Meets the requirements of MIL-PRF-28800F for Class 3 Equipment
Safety: IEC 61010-1:2010: Pollution degree 2
Altitude: Operating: 4,000 m; Storage: 12,000 m
EMC: IEC 61326-1: Basic Electromagnetic Environment
CISPR 11: Group 1, Class A
