AC High Voltage Test: 5kV AC
AC Output Frequency: 50Hz or 60Hz, adjustable
AC Output Waveform: Sine wave, 1.3< crest factor <1.5
Leakage Current for AC High Voltage Test:
+ Range: 0.01-20.00mA
+ Resolution: 0.01 A
+ Accuracy: ± ( 2 % set + 2 digits)
DC High Voltage Test: 6kV DC
Leakage Current for DC High voltage Test
+ Range: 0.01-10.00mA
+ Resolution: 0.01 A
+ Accuracy: ± (2 % set + 2 digits)
AC-DC Voltage Adjustment:
+ Range: 0-5000VAC
+ Range: 0-6000V DC
+ Resolution: 1V
+ Accuracy: ± (2 % +5V)
Voltage Stability: 1 % set + 5V
Rise Time
+ Resolution: 0.1 S
+ Accuracy: ± (0.1 % set +0.05 s )
Test Time
+ Range: 0.5-999.9 s
+ Resolution: 0.1 s
+ Accuracy: ± (0.1% set +0.05 s)
ARK Recognition: ARK recognition on: 1-9 adjustable, ARK recognition off: 0
Insulation Resistance Test: 1000V DC
Insulation Test Voltage Adjustment:
+ Range: 500-1000V DC
+ Resolution: 1V
+ Accuracy: ± ( 2 % set+5 V)
Insulation Test Voltage Display: Resolution: 10 V
Insulation Test Resistance Display:
+ Range: 1.000-2000 MΩ
+ Accuracy: ± (5 % reading +3 digits) (1-1000 M Q)
+ Accuracy: ±(10% reading +3 digits) (1000-2000 M Ω)
Insulation Resistance Upper Limit Setting: 0- 2000 M Ω, 0: No limit
Insulation Resistance Lower Limit Setting: 1.0-999.9 M Ω
