Resistance range: 8000μ , 4000μ , 2000μ full-scale
Resolution: 32, 16, 8 micro ohm
Accuracy: Value + 2 % + Resolution
Current: 100 A DC full-scale, for up to 1 sec
Output: 0 to 5 V DC
Software: MDCRM software for on screen analysis of test results
Power: 230 V AC + 5%, 50 Hz + 10%
Dimensions: 430mm(L) X 435mm(W) X 188 mm(H)
Weight: 10 Kg Approx.
HS Code: 90318000
Test leads set for
Connection between MDCRM to Breaker / GIS – 15 meter
Connection between MDCRM to MCBOA - 5 meter
Accessories:
Contact Timing Cable, 15m: 3 Nos
Breaker Control Cable, 7m: 1 No.
Master Earthing Cable 7m: 1 No.
Mains cord, 3m: 1 Nos
Spare Fuses: 1 Set
Soft Carrying Case For Test Leads: 1 No.
PC Downloading & Analysis Software on CD: 1 No
Operation cum Instruction Manual: 1 Set
