Molex 224246-1011 ພິບບີ Receptacle Versa Color Vert Header Thru Hole Dual Row 10 Ckts (Au) GloWire Nat Tray

Pitch: 3 mm (0.118 in)

Application: Wire-to-Board, Power

Row Spacing: 3 mm (0.118 in)

Housing Color: Natural

Contact Gender: Socket (Female)

Current Rating: 12 A

Housing Gender: Receptacle

Mounting Angle: Straight

Mounting Style: PCB Mount

Number of Rows: 2 Row

Voltage Rating: 600 VAC, 600 VDC

Contact Plating: Gold

Contact Material: Copper

Housing Material: Liquid Crystal Polymer (LCP)

Termination Style: Solder Pin

Flammability Rating: UL 94 V-0

Number of Positions: 10 Position

Insulation Resistance: 1 GOhms

Termination Post Length: 3.18 mm (0.125 in)

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
