Gain: 0.03 dBi to 5.3 dBi
VSWR: 3
Style: Ceramic
Width: 25.5 mm
Height: 0.852 mm
Length: 49 mm
Bandwidth: 6.508 GHz
Frequency: 617 MHz to 7.125 GHz
IP Rating: IP68
Impedance: 50 Ohms
Application: Access Points, Routers, Gateways, Set Top Box, Multi-band Equipment, Appliances, Wireless Devices
Power Rating: 2 W
Qualification: AEC-Q200
Mounting Style: PCB Mount
Frequency Range: 617 MHz to 7.125 GHz
Number of Bands: 1 Band
Center Frequency: 617 MHz, 915 MHz, 2.45 GHz, 5.5 GHz, 6 GHz, 7 GHz
Mechanical Style: Chip
Maximum Frequency: 7.125 GHz
Minimum Frequency: 617 MHz
Termination Style: SMD/SMT
Moisture Sensitive: Yes
Protocol - Sub GHz: ISM
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GNSS, GPS
Protocol - WiFi - 802.11: ISM, ANT, WiFi, WiFi 802.11, WLAN, WiFi 6, WiFi 6E, WiMAX, WHDMI
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DSRC
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
