Inputs: 4 low-power IEPE inputs; 1 mA / 17 V; TEDS support, IEEE1451.4, Template 25
Sensors: Low-power IEPE, sensitivity 0.8 - 120 mV/ms^-2
Measuring ranges (with sensor 1 mV/ms^-2): Acceleration: 800 m/s²; velocity: 100 - 10000 mm/s; displacement: 250 - 15000 µm
Linearity range: > 75 dB for ± 6 % error
Noise: < 0,003 m/s²
Frequency analysis (FFT): 125 lines for X/Y/Z, peak spectrum of acceleration, 3 - 240 / 6 - 480 / 12 - 960 / 24 - 1920 Hz
Data memory: Flash, 10 000 measurements, 1000 FFTs, each with date, time and comment
Display: OLED, 128 x 160 pixels, colored
USB interface: USB 2.0, full-speed, CDC mode (virtual COM port), via cable VM2x-USB
Batteries: 3 accumulators HR03 or Alkaline cells LR03 (size AAA), 10 - 14 hours operation
Temperature range: -4 .. 140°F (-20 .. 60°C), < 95 % relative humidity, no condensation
Dimensions without connectors; weight: 125x65x27mm; 140g (5x2.5x1.1in; 5oz)
Standard accessories: USB cable VM2x-USB, batteries, instruction manual, plastic carrying case
Optional accessories:
Triaxial seat accelerometer: ordering no. KS963B100-S
Triaxial accelerometer (hand-arm): ordering no. KS903B10
Triaxial accelerometer (machine vibration): ordering no. KS903B100
Uniaxial accelerometer for channel A: ordering no. KS78B100
Triaxial sensor cable (3 m): ordering no. 091-CMR-B711-3
Uniaxial sensor cable (3 m): ordering no. VM31-A
Handle adapter for curved surfaces (M5): ordering no. 141
Hand-held adapter for curved surfaces (M5): ordering no. 143
