Repeatability: ±0.5% of Reading
Reproducibility: ±0.3% of Reading
Pressure Range: 100 Torr
Pressure Accuracy: 0.25% of Reading
Proof Pressure: 45 psia
Burst Pressure: 150 psig
Minimum Penumatic Air Supply Pressure: 80 psig
Maximum Penumatic Air Supply Pressure: 100 psig
Span Temperature Coefficient: <0.002% Reading/°C
Warm-up Time: 60 minutes
Operating Temperature: 10 - 40°C
Temperature Display: 0 - 100°C
Temperature Accuracy: ± 2°C
Temperature Resolution: 0.1°C
Storage Humidity: 0 - 95% RH non-condensing
Storage Temperature: -20 - 60°C (-4 - 160°F)
Control Interface: DeviceNet: 5-pin DeviceNet Micro Connector Type
EtherCAT: Dual RJ-45 (Comm.) M8 Male 5pin (PWR)
Diagnostic Interface: Ethernet RJ-45 female
Input Voltage: DeviceNet: 11-25 VDC
EtherCAT: 11-25VDC +24 VDC (±10%)
Dimensions: 6.98 x 10.0 x 10.0 in. (177.3 x 254.0 x 254.0 mm) (height x width x length)
Weight: 23.9 lbs (10.9 kg)
Compliance: CE
Temperature Readout Units: °C
Full Scale Verification Range: 5 - 3000 sccm (N2 equivalent)
Typical Accuracy: ±1.0% of Reading
For specific range please check the attachment below!
