Control Range: 2-100% of Full Scale
Full Scale Flow Range: 5-50,000 sccm
Fitting Type: Compatible with: 6 mm Swagelok, 8 mm Swagelok, 10 mm Swagelok, 12 mm Swagelok, 0.125 in. Swagelok (for 1000 sccm N2 equivalent or below), 0.25 in. Swagelok, 0.5 in. Swagelok, 0.375 in. Swagelok, Swagelok 4 VCO male, Swagelok 4 VCR male, Swagelok 8 VCR male, Swagelok 8 VCO Male, Swagelok 2 VCR Male (for 1000 sccm N2 equivalent or below), KF-16
Seal Material: Viton®, Buna-N, Neoprene®, EPDM, Kalrez
Connector: EtherCAT, DeviceNet, RS485 (9 pin connector), Profibus (1480 Compatible), Profibus (1179B Compatible), PROFINET, 9 pin D connector (Analog 0-5 VDC), 9 Pin D connector, Tied Grounds (Analog 0-5 VDC), 15 pin D connector (Analog 0-5 VDC), 15 pin D connector, Tied Grounds (Analog 0-5 VDC), 15 pin D connector (Analog 4-20 mA)
Maximum Inlet Pressure: 150 psig
Normal Operating Pressure Differential: 10-5000 sccm; 10-40 psid, 10000-0000 sccm; 15-40 psid, 30000-50000 sccm; 25-40 psid
Proof Pressure: 1000 psig
Burst Pressure: 1500 psig
Typical Accuracy: ± 1% of set point for 20 to 100% Full Scale, ± 0.2% of Full Scale for 2 to 20% Full Scale
Repeatability: ± 0.3% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: < 0.05% of Full Scale/°C
Span Temperature Coefficient: < 0.08% of Reading/°C
Inlet Pressure Coefficient: < 0.02% of Reading/psi
Typical Settling Time: <750 msec, typical above 5% Full Scale
Warm-up Time: 30 minutes
Operating Temperature: 10-50°C
Storage Humidity: 0-95% Relative Humidity, non-condensing
Storage Temperature: -20° to 80°C
Wetted Materials: 316L S.S. VAR, 316 S.S., Elgiloy®, KM-45
Surface Finish: 16µ inch average Ra
Weight: 3 lbs (1.4 kg)
Compliance: CE
For specific range please check the attachment below!
