Full Scale Flow Range: 15-14,000 sccm (N2)
Maximum Inlet Pressure: 80 psig
Proof Pressure: 232 psi/16 bar
Burst Pressure: 1000 psi/70 bar
Measurement Range: 0.1-100% of Full Scale
Typical Accuracy: ±0.8% of Reading
Repeatability: ±0.2% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: ≤0.005% of Full Scale/°C
Span Temperature Coefficient: ≤0.06% of Reading/°C
Pressure Coefficient: <0.025% of Reading/psi
Warm-up Time: ≤1 min
Operating Temperature: 10-50°C (32-122°F)
Storage Humidity: 0-95% relative humidity, non-condensing
Storage Temperature: 0-60°C (32-140°F)
Power Requirements: 24 VDC @ (±10%), <2 watts
Flow Input Output Signal: 0-5 VDC (0-10 VDC, optional)
Analog I/O Connector: 9-pin Type D
Weight: 0.45 lbs (204 grams) (VCR)
Compliance: CE (Electrical Analog I/O)
For specific range please check the attachment below!
